The machine adapts full seal form. All parts are made of stainless steel. It is equipped with three grades of purifying apparatus. The filtered air reaches the requirement of one hundred grades. The cooling appetites of wall is installed at the cylinder body and top. It makes the wall temperature less than 80C.Air sweeping device is installed inside the drying tower. The dried immersed ointment powder is raised greatly. Moreover it can not appear the phenomenon of carbonization and degeneration. The ratio of received powder is raised greatly. Moreover, it cannot produce the phenomenon of medicine mixing and wall staying. Basic principle: high-speed centrifuge atomizing apparatus for immersed ointment of traditional Chinese medicine is an application of centrifuge at atomizing technique Special raw material. It is an apparatus using high-speed at atomizing drier.

1. Being adapted three-grade air purification. the inlet air reaches the requirement of one hundred thousand grade:

2. Being adapted wall cooling device. the temperature of inner wall will be 80CEven if raw material is stayed on the wall, it cannot carbonize.

3. lts whole volume is 3.5 times of standard LPG high-speed atomizing drier,

4. Being adapted quick washing device, it can meet the requirements of

production for varieties products:

5. Being adapted quick washing device, there is no powder dust out, it is

conformity with the requirement of GMP.

6. Being adapted air sweeping device the clean effect is satisfied!

7. Equipped two sets of atomizer and adapted frequency control.

8. Adapted PLC control and display and adapted frequency control.

9. Equipped with washing device.

10. Adapt the seal method to transport dry air.

Tower body has jacket of air.

Tower body is equipped with automatic vibration and beating device;

Tower body and pipe line have cleaning hole and sewage discharge hole that can open quickly.

Automatic temperature control feeding tank;

Accompanied parts of high pressure washing tower;

The parts that can contact with raw material are made of stainless steel fully;

The collecting for raw material adapts two grade cyclone duster or one-grade cyclone duster and one-grade damp duster :

The temperature of inlet air can be controlled automatically and continuously:

Equipped with air sweeping device.
